Пропускная способность в режиме Firewall (Base/Plus) 37 Gbps
Пропускная способность в режиме Threat Prevention (Base/Plus) 7.4 Gbps
Пропускная способность в режиме IPS (Base/Plus) 15 Gbps
Пропускная способность в режиме NGFW (Base/Plus) 13 Gbps
Пропускная способность VPN (Base/Plus) 9.81 Gbps
Максимальное число одновременно поддерживаемых сессий (Base/Plus) 4/8/16 M
Сетевые интерфейсы (8) 10/100/1000 RJ-45, 2 Network expansion slot
ЦПУ 1x CPUs, 8 physical cores, 16 virtual cores
ОЗУ 16, 32 and 64 GB memory options
Жесткий диск 1x 480GB SSD storage (2x in Plus)
Консольный порт 1 x RJ-45, 1x USB-C
Порты USB 2 x USB 3.0

Информация для заказа (Part Numbers):

BASE CONFIGURATION
6900 Security Gateway Base configuration, includes 10x 1GbE copper ports, 16GB RAM, 1 SSD, 1 AC PSU CPAP-SG6900
6900 Security Gateway Plus configuration, includes 10x 1GbE copper ports, 4x 10GbE SFP+ ports, 4x SR transceivers, 32GB RAM, 2x SSD, 2x AC PSU, Lights-out Management CPAP-SG6900-PLUS
MEMORY
Memory upgrade kit from 16GB to 32GB for 6900 appliance CPAC-RAM16GB-6900
Memory upgrade kit from 16GB to 64GB for 6900 appliance CPAC-RAM48GB-6900
Memory upgrade kit from 32GB to 64GB for 6900 appliance CPAC-RAM32GB-6900
SPARES AND MISCELLANEOUS
480GB SSD for 6900 Security Gateways CPAC-SSD-480G-6900
Additional/Replacement AC Power Supply for 6900 appliances CPAC-PSU-6600/6900
Lights Out Management module CPAC-LOM-C
Slide rails for 6000 Security Gateways (22” — 32”) CPAC-RAILS-6000
Extended slide rails for 6000 Security Gateways (24” — 36”) CPAC-RAILS-EXT-6000
INTERFACE CARDS AND TRANSCEIVERS
8 Port 10/100/1000 Base-T RJ45 interface card CPAC-8-1C-C
4 Port 1000Base-F SFP interface card; requires additional 1000Base SFP transceivers CPAC-4-1F-C
SFP transceiver module for 1G fiber ports — long range (1000Base-LX) CPAC-TR-1LX-C
SFP transceiver module for 1G fiber ports — short range (1000Base-SX) CPAC-TR-1SX-C
SFP transceiver to 1000 Base-T RJ45 (Copper) CPAC-TR-1T-C
4 Port 10GBase-F SFP+ interface card CPAC-4-10F-C
SFP+ transceiver module for 10G fiber ports — long range (10GBase-LR) CPAC-TR-10LR-C
SFP+ transceiver module for 10G fiber ports — short range (10GBase-SR) CPAC-TR-10SR-C
2 Port 40GBase-F QSFP+ interface card CPAC-2-40F-C
QSFP+ transceiver module for 40G fiber ports — long range (40GBase-LR) CPAC-TR-40SR-QSFP-300m
QSFP+ transceiver module for 40G fiber ports — short range (40GBase-SR) CPAC-TR-40LR-QSFP-10Km
