Throughput: Firewall (FW) + Application Visibility and Control (AVC) (1024B) 54 Gbps
Throughput: FW + AVC + Intrusion Prevention System (IPS) (1024B) 48 Gbps
Maximum concurrent sessions, with AVC 35 million
Maximum new connections per second, with AVC 380K
TLS (Hardware Decryption) 10 Gbps
Throughput: NGIPS (1024B) 57 Gbps
IPSec VPN throughput (1024B TCP w/Fastpath) 20 Gbps
Maximum VPN Peers 20,000
Clustering Up to 16 security modules across up to 16 different Firepower 9300 chassis
High availability and clustering Active/active and active/standby
Dimensions (H x W x D) 5.25 x 17.5 x 32 in. (13.3 x 44.5 x 81.3 cm)
Form factor (rack units) 3 Rack Units (3RU), fits standard 19-in. (48.3-cm) square-hole rack
Network modules 8 x 10 Gigabit Ethernet Enhanced Small Form-Factor Pluggable (SFP+) network modules
4 x 40 Gigabit Ethernet Quad SFP+ network modules
2 x 100 Gigabit Ethernet Quad SFP28 network modules
4 x 100 Gigabit Ethernet Quad SFP28 network modules
Integrated network management ports 1 x Gigabit Ethernet copper port (on supervisor)
Serial port 1 x RJ-45 console
USB 1 x USB 2.0
Storage Up to 4.8 TB per chassis (1.6 TB per security module in RAID-1 configuration)
Maximum number of interfaces Up to 24 x 10 Gigabit Ethernet (SFP+) interfaces; up to 8 x 40 Gigabit Ethernet (QSFP+) interfaces with 2 network modules; up to 8 x 100 Gigabit Ethernet interfaces with two network modules
AC input voltage 200 to 240V AC
AC maximum input current 15.5A to 12.9A
AC maximum output power 2500W
AC frequency 50 to 60 Hz
Efficiency (at 50% load) 92%
Redundancy 1+1
Fans 4 hot-swappable fans
Noise 75.5 dBA at maximum fan speed
Rack mountable Yes, mount rails included (4-post EIA-310-D rack)
Weight 105 lb (47.7 kg) with one security module; 135 lb (61.2 kg) fully configured
