 | FortiGate 200F | FortiGate 201F | |
| GE RJ45 Ports | 16 | 16 | |
| GE RJ45 Management/HA Ports | 1/1 | 1/1 | |
| GE SFP Slots | 8 | 8 | |
| 10GE SFP+ FortiLink Slots (default) | 2 | 2 | |
| 10GE SFP+ Slots | 2 | 2 | |
| Internal Storage | — | 1x 480 GB SSD | |
| USB Port | 1 | ||
| RJ45 Console Port | 1 | ||
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 27 / 27 / 11 Gbps | ||
| Firewall Latency (64 byte UDP packets) | 4.78 μs | ||
| Firewall Throughput (Packets Per Second) | 16.5 Mpps | ||
| Concurrent Sessions (TCP) | 3 Million | ||
| New Sessions/Second (TCP) | 280,000 | ||
| Firewall Policies | 10,000 | ||
| IPsec VPN Throughput (512 byte) | 13 Gbps | ||
| Gateway-to-Gateway IPsec VPN Tunnels | 2,500 | ||
| Client-to-Gateway IPsec VPN Tunnels | 16,000 | ||
| SSL-VPN Throughput | 2 Gbps | ||
| Concurrent SSL-VPN Users (Recommended Maximum) | 500 | ||
| SSL Inspection Throughput (IPS, avg. HTTPS) | 4 Gbps | ||
| SSL Inspection CPS (IPS, avg. HTTPS) | 3,500 | ||
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 300,000 | ||
| Application Control Throughput (HTTP 64K) | 13 Gbps | ||
| Virtual Domains (Default / Maximum) | 10 / 10 | ||
| High Availability Configurations | Active-Active, Active-Passive, Clustering | ||
| IPS Throughput | 5 Gbps | ||
| NGFW Throughput | 3.5 Gbps | ||
| Threat Protection Throughput | 3 Gbps | ||
