 | FortiGate 3800D | FortiGate 3800D-DC | |
| 100 GE CFP2 Slots | 4 | ||
| 40 GE QSFP+ Slots | 4 | ||
| 10 GE SFP+ Slots | 8 (supports GE SFP) | ||
| GE RJ45 Management Ports | 2 | ||
| Included Transceivers | 2x SFP+ (SR 10 GE) | ||
| Onboard Storage | 2x 480 GB SSD | ||
| USB Ports (Client / Server) | 1 / 1 | ||
| RJ45 Console Port | 1 | ||
| Firewall Throughput (1518 / 512 / 64 byte UDP packets) | 320 / 300 / 150 Gbps | ||
| Firewall Latency (64 byte UDP packets) | 5 μs | ||
| Firewall Throughput (Packets Per Second) | 262.5 Mpps | ||
| Concurrent Sessions (TCP) | 95 Million | ||
| New Sessions/Second (TCP) | 480,000 | ||
| Firewall Policies | 200,000 | ||
| IPsec VPN Throughput (512 byte) | 135 Gbps | ||
| Gateway-to-Gateway IPsec VPN Tunnels | 40,000 | ||
| Client-to-Gateway IPsec VPN Tunnels | 200,000 | ||
| SSL-VPN Throughput | 10 Gbps | ||
| Concurrent SSL-VPN Users (Recommended Maximum) | 30,000 | ||
| SSL Inspection Throughput (IPS, avg. HTTPS) | 14.4 Gbps | ||
| SSL Inspection CPS (IPS, avg. HTTPS) | 9,000 | ||
| SSL Inspection Concurrent Session (IPS, avg. HTTPS) | 7 Million | ||
| Application Control Throughput (HTTP 64K) | 44 Gbps | ||
| Virtual Domains (Default / Maximum) | 10 / 500 | ||
| High Availability Configurations | Active-Active, Active-Passive, Clustering | ||
| IPS Throughput | 30 Gbps | ||
| NGFW Throughput | 20 Gbps | ||
| Threat Protection Throughput | 13 Gbps | ||
