Throughput Up to 80Gbps
Standard interface 2×100GE (QSFP28) + 2×40GE (QSFP+) + 20×10GE (SFP+)
Deployment mode in-line; off-line (static defense); off-line (Dynamic defense)
Function Options for detecting or cleaning
External Bypass Multi mode or single mode GE link; Multi mode or single mode 10GE link
Height × Width × Depth 44.4mm × 442mm × 600mm (1U)
Weight 12kg
Power supply Rated input voltage:
AC: 100 V to 240 V, 50 Hz/60 Hz
Maximum input voltage range:
AC: 90 V to 264 V, 47 Hz to 63 Hz
Power Consumption 566W
Power redundancy AC: 1+1 power redundancy
Safety certifications Electro Magnetic Compatibility (EMC) certification
CB, CCC, CE-SDOC, ROHS, REACH&WEEE(EU), C-TICK, ETL, FCC&IC, VCCI, BSMI



Function Description
Defense against protocol abuse attacks Defense against Land, Fraggle, Smurf, WinNuke, Ping of Death, Teardrop, and TCP error flag attacks
Web application protection Defense against HTTP GET flood, HTTP POST flood, HTTP slow header, HTTP slow post, HTTPS flood, SSL DoS/DDoS, WordPress reflection amplification, RUDY, and LOIC attacks; packet validity check
Defense against scanning and sniffing attacks Defense against address and port scanning attacks, and attacks using Tracert packets and IP options, such as IP source route, timestamp, and record route
DNS application protection Defense against DNS query flood, DNS reply flood, and DNS cache poisoning attacks; source limit
Defense against network-type attacks Defense against SYN flood, SYN-ACK flood, ACK flood, FIN flood, RST flood, TCP fragment flood, UDP flood, UDP fragment flood, IP flood, ICMP flood, TCP connection flood, sockstress, TCP retransmission, and TCP empty connection attacks
SIP application protection Defense against SIP flood/SIP methods flood attacks, including Register, Deregistration, Authentication, and Call flood attacks; source limit
Defense against UDP-based reflection amplification attacks Defense against NTP, DNS, SSDP, Chargen, TFTP, SNMP, NetBIOS, QOTD, Quake Network Protocol, Portmapper, Microsoft SQL Resolution Service, RIPv1, and Steam
Protocol reflection amplification attacks
Filter IP, TCP, UDP, ICMP, DNS, SIP, and HTTP packet filters
Location-based filtering Traffic block or limit based on the source IP address location
Attack signature database RUDY, slowhttptest, slowloris, LOIC, AnonCannon, RefRef, ApacheKill, and ApacheBench attack signature databases; automatic weekly update of these signature databases
IP reputation Tracking of most active 5 million zombies and automatic daily update of the IP reputation database to rapidly block attacks; local access IP reputation learning to create dynamic IP reputation based on local service sessions, rapidly forward service access traffic, and enhance user experience
Management functions Account management and permission allocation; defense policy configuration and report display based on Zones (up to 100,000 Zones, namely tenants); device performance monitoring; source tracing and fingerprint extraction through packet capture; email, short message, and audio alarms; log dumping; dynamic baseline learning
Report functions Comparison of traffic before and after cleaning; top N traffic statistics; application-layer traffic comparison and distribution; protocol distribution; traffic statistics based on the source location; attack event details; top N attack events (by duration or number of packets);
distribution of attacks by category; attack traffic trend; DNS resolution success ratio; application-layer top N traffic statistics (by source IP address, HTTP URI, HTTP HOST, and domain name); download of reports in HTML/PDF/Excel format; report push via email;
periodical generation of daily, weekly, monthly, and yearly reports; self-service portal for tenants
Deployment mode In-line or off-line deployment
Traffic diversion and injection Traffic diversion: supports manual, and PBR or BGP based automatic traffic diversion.
Traffic injection: supports static route injection, MPLS VPN injection, MPLS LSP injection, GRE tunnel injection, Layer 2 injection, PBR based injection, etc
